    Plano-Convex Lenses

    Plano-Convex Lenses are Optical Lenses with a positive focal length. Plano-Convex Lenses are ideal for light collimation or for focusing applications utilizing monochromatic illumination, in a range of industries including industrial, pharmaceutical, robotics, or defense. PCX Lenses have one convex surface. For maximum efficiency, the second, plano (flat) surface should face the desired focal plane. Plano-Convex lenses are commonly used in a wide range of applications or industries.

    Edmund Optics offers the world’s largest inventory of off-the-shelf optical components, which includes a large variety of Plano-Convex Lenses. Edmund Optics’ PCX lenses are available in a range of coating or substrate options. Anti-reflection coatings range from the Ultraviolet (UV) to the Infrared (IR), including UV-AR, UV-VIS, MgF2, VIS 0°, VIS-NIR, NIR I, NIR II, or Telecom-NIR. Additional coatings designed specifically for laser wavelengths, such as 266nm, 355nm, 532nm, or 1064nm are also offered. Germanium (Ge), Silicon (Si), or Zinc Selenide (ZnSe) substrates are ideal for Infrared (IR) applications.

    Uncoated Plano-Convex (PCX) Lenses
    TECHSPEC® components are designed, specified, or manufactured by Edmund Optics. Learn More

    Uncoated Plano-Convex (PCX) Lenses
    • Wavelength Range of 350-2200nm
    • Precision Diameter and Centration Tolerances Allow for Easy OEM Integration
    • Wide Variety of Diameters, Focal Lengths, and Coatings
    • Anti-Reflection Coating Options: MgF2, VIS 0°, VIS-NIR, NIR I, NIR II, VIS-EXT, and YAG-BBAR
    MgF<sub>2</sub> Coated Plano-Convex (PCX) Lenses
    TECHSPEC® components are designed, specified, or manufactured by Edmund Optics. Learn More

    MgF2 Coated Plano-Convex (PCX) Lenses
    VIS 0° Coated Plano-Convex (PCX) Lenses
    TECHSPEC® components are designed, specified, or manufactured by Edmund Optics. Learn More

    VIS 0° Coated Plano-Convex (PCX) Lenses
    NIR I Coated Plano-Convex (PCX) Lenses
    TECHSPEC® components are designed, specified, or manufactured by Edmund Optics. Learn More

    NIR I Coated Plano-Convex (PCX) Lenses
    NIR II Coated Plano-Convex (PCX) Lenses
    TECHSPEC® components are designed, specified, or manufactured by Edmund Optics. Learn More

    NIR II Coated Plano-Convex (PCX) Lenses
    VIS-EXT Coated Plano-Convex (PCX) Lenses
    TECHSPEC® components are designed, specified, or manufactured by Edmund Optics. Learn More

    VIS-EXT Coated Plano-Convex (PCX) Lenses
    • Visible Broadband Anti-Reflection Coating with Extended UV Performance
    • AR Coated to Provide <0.5% Reflectance per Surface for 350 - 700nm
    • Designed for 0° Angle of Incidence
    • Various Coating Options: Uncoated, MgF2, VIS 0°, VIS-NIR, NIR I, NIR II, and YAG-BBAR
    VIS-NIR Coated Plano-Convex (PCX) Lenses
    TECHSPEC® components are designed, specified, or manufactured by Edmund Optics. Learn More

    VIS-NIR Coated Plano-Convex (PCX) Lenses
    YAG-BBAR Coated Plano-Convex (PCX) Lenses
    TECHSPEC® components are designed, specified, or manufactured by Edmund Optics. Learn More

    YAG-BBAR Coated Plano-Convex (PCX) Lenses
    • Optimized for R<0.25% @ Both 532nm and 1064nm
    • AR Coated to Provide <1.0% Reflectance per Surface for 500 - 1100nm
    • Designed for 0° Angle of Incidence
    • Various Coating Options: Uncoated, MgF2, VIS 0°, VIS-NIR, NIR I, NIR II, and VIS-EXT
    Micro Plano-Convex (PCX) Lenses
    TECHSPEC® components are designed, specified, or manufactured by Edmund Optics. Learn More

    Micro Plano-Convex (PCX) Lenses
    • Diameters as Small as 1mm
    • Short Focal Lengths for Integration into Compact Devices
    • Broadband Antireflection Coating Options Available
    Ultrafast Thin Plano-Convex (PCX) Lenses
    TECHSPEC® components are designed, specified, or manufactured by Edmund Optics. Learn More
    New
    ×

    Ultrafast Thin Plano-Convex (PCX) Lenses
    • Ultra-Thin Center Thickness to Limit GDD
    • Ideal for Ultrafast and Laser Optics Applications
    • UV or IR Grade Fused Silica Substrates
    405nm Laser Line Coated Plano-Convex (PCX) Lenses
    TECHSPEC® components are designed, specified, or manufactured by Edmund Optics. Learn More

    405nm Laser Line Coated Plano-Convex (PCX) Lenses
    532nm Laser Line Coated Plano-Convex (PCX) Lenses
    TECHSPEC® components are designed, specified, or manufactured by Edmund Optics. Learn More

    532nm Laser Line Coated Plano-Convex (PCX) Lenses
    633nm Laser Line Coated Plano-Convex (PCX) Lenses
    TECHSPEC® components are designed, specified, or manufactured by Edmund Optics. Learn More

    633nm Laser Line Coated Plano-Convex (PCX) Lenses
    785nm Laser Line Coated Plano-Convex (PCX) Lenses
    TECHSPEC® components are designed, specified, or manufactured by Edmund Optics. Learn More

    785nm Laser Line Coated Plano-Convex (PCX) Lenses
    1064nm Laser Line Coated Plano-Convex (PCX) Lenses
    TECHSPEC® components are designed, specified, or manufactured by Edmund Optics. Learn More

    1064nm Laser Line Coated Plano-Convex (PCX) Lenses
    1550nm Laser Line Coated Plano-Convex (PCX) Lenses
    TECHSPEC® components are designed, specified, or manufactured by Edmund Optics. Learn More

    1550nm Laser Line Coated Plano-Convex (PCX) Lenses
    UV Fused Silica Plano-Convex (PCX) Lenses
    TECHSPEC® components are designed, specified, or manufactured by Edmund Optics. Learn More

    UV Fused Silica Plano-Convex (PCX) Lenses
    • UV-Grade Fused Silica
    • Wavelength Range of 200nm to 2.2µm
    • Variety of Coating Options Available
    405nm Laser Line Coated Fused Silica PCX Lenses
    TECHSPEC® components are designed, specified, or manufactured by Edmund Optics. Learn More

    405nm Laser Line Coated Fused Silica PCX Lenses
    • <0.25% Reflection at 405nm for 405nm Diodes
    • 5 - 50mm Diameters Available
    • 10 - 250mm EFL Designs Available
    • 532nm, 633nm, 1064nm, and 1550nm V-Coated Options Offered
    532nm Laser Line Coated Fused Silica PCX Lenses
    TECHSPEC® components are designed, specified, or manufactured by Edmund Optics. Learn More

    532nm Laser Line Coated Fused Silica PCX Lenses
    • <0.25% Reflection at 532nm for 2nd Harmonic Nd:YAG Applications
    • 5 - 50mm Diameters Available
    • 10 - 250mm EFL Designs Available
    • 405nm, 633nm, 1064nm, and 1550nm V-Coated Options Offered
    633nm Laser Line Coated Fused Silica PCX Lenses
    TECHSPEC® components are designed, specified, or manufactured by Edmund Optics. Learn More

    633nm Laser Line Coated Fused Silica PCX Lenses
    • <0.25% Reflection at 633nm for HeNe Applications
    • 5 - 50mm Diameters Available
    • 10 - 250mm EFL Designs Available
    • 405nm, 532nm, 1064nm, and 1550nm V-Coated Options Offered
    1064nm Laser Line Coated Fused Silica PCX Lenses
    TECHSPEC® components are designed, specified, or manufactured by Edmund Optics. Learn More

    1064nm Laser Line Coated Fused Silica PCX Lenses
    • <0.25% Reflection at 1064nm for Fiber and Nd:YAG Applications
    • 5 - 50mm Diameters Available
    • 10 - 250mm EFL Designs Available
    • 405nm, 532nm, 633nm, and 1550nm V-Coated Options Offered
    1550nm Laser Line Coated Fused Silica PCX Lenses
    TECHSPEC® components are designed, specified, or manufactured by Edmund Optics. Learn More

    1550nm Laser Line Coated Fused Silica PCX Lenses
    • <0.25% Reflection at 1550nm
    • 5 - 50mm Diameters Available
    • 10 - 250mm EFL Designs Available
    • 405nm, 532nm, 633nm, and 1064nm V-Coated Options Offered
    Laser Grade Plano-Convex (PCX) Lenses
    TECHSPEC® components are designed, specified, or manufactured by Edmund Optics. Learn More

    Laser Grade Plano-Convex (PCX) Lenses
    • Guaranteed Laser Damage Threshold
    • 10-5 Surface Quality
    • λ/10 Surface Accuracy
    Laser Focusing Singlet Lenses
    TECHSPEC® components are designed, specified, or manufactured by Edmund Optics. Learn More
    New
    ×

    Laser Focusing Singlet Lenses
    • Mounted N-BK7 Lenses for Easy Integration into Laser Systems
    • Positive Focal Lengths from 60mm to 120mm
    • AR Coated for Nd:YAG Laser Lines
    &lambda;/20 PCX Lenses
    TECHSPEC® components are designed, specified, or manufactured by Edmund Optics. Learn More

    λ/20 PCX Lenses
    • λ/20 Surface Accuracy
    • Available Uncoated or with a Variety of Nd:YAG Laser Coating Options
    • Includes Full Data Package with Interferogram and Measured Results for Geometric Tolerances

    Large PCX Condenser Lenses
    Large PCX Condenser Lenses
    • Large Sizes Available – 100 to 250mm Diameter
    • Polished Surfaces for Superior Precision vs. Cast Optics
    • Wavelength Range of 350-2200nm
    Calcium Fluoride Plano-Convex (PCX) Lenses
    TECHSPEC® components are designed, specified, or manufactured by Edmund Optics. Learn More

    Calcium Fluoride Plano-Convex (PCX) Lenses
    • Greater than 90% Transmission from 200nm - 7μm
    • Low Index of Refraction
    • Vacuum Grade UV Substrate
    Zinc Selenide (ZnSe) Plano-Convex (PCX) Lenses
    TECHSPEC® components are designed, specified, or manufactured by Edmund Optics. Learn More
    New
    ×

    Zinc Selenide (ZnSe) Plano-Convex (PCX) Lenses
    • Edmund Optics® Designed, II-VI Manufactured
    • Premier Grade ZnSe Material
    • Uncoated or Broadband AR Coating Options
    Germanium Plano-Convex (PCX) Lenses
    TECHSPEC® components are designed, specified, or manufactured by Edmund Optics. Learn More

    Germanium Plano-Convex (PCX) Lenses
    • Wavelength Range of 2 - 16μm
    • Rugged, Durable Material
    • Ideal for Defense, Security, and Thermal Imaging Applications
    • Additional Infrared Lenses Available in Popular Substrates
    Silicon Plano-Convex (PCX) Lenses
    TECHSPEC® components are designed, specified, or manufactured by Edmund Optics. Learn More

    Silicon Plano-Convex (PCX) Lenses
    • Wavelength Range of 1.2 - 7μm
    • Low Density and Dispersion
    • Focal Lengths of 25 – 250mm Available
    • Additional Infrared Lenses Available in Popular Substrates
    Zinc Selenide Plano-Convex (PCX) Lenses
    Zinc Selenide Plano-Convex (PCX) Lenses
    • Usable Transmission Range is 600nm to 16μm
    • Low Dispersion
    Standard Silicon Plano-Convex (PCX) Lenses
    Standard Silicon Plano-Convex (PCX) Lenses
    • Low Dispersion and Density
    • Transmission from 1.2 to 7μm
    Plano-Convex (PCX) and Simple Lens Kits
    TECHSPEC® components are designed, specified, or manufactured by Edmund Optics. Learn More

    Plano-Convex (PCX) and Simple Lens Kits
    • Simple Lens Kits Include PCX, DCX, PCV, and DCV Lenses
    • Kits Available for 12mm and 25mm Diameter Lenses
    • Uncoated or BBAR Coating Options
    N-K5 Lenses
    N-K5 Lenses
    • N-K5 Substrate
    • Various Anti-Reflection (AR) Coatings
    • PCX and DCX Options Available
    Telecom-NIR Coated Plano-Convex (PCX) Lenses
    Telecom-NIR Coated Plano-Convex (PCX) Lenses
    • Positive Focal Length
    • Micro PCX Lenses for Collecting and Focusing Light
    • Various Coatings Available: Uncoated, MgF2, and NIR I
    980nm Laser Line Coated Plano-Convex (PCX) Lenses
    TECHSPEC® components are designed, specified, or manufactured by Edmund Optics. Learn More

    980nm Laser Line Coated Plano-Convex (PCX) Lenses
    1310nm Laser Line Coated Plano-Convex (PCX) Lenses
    TECHSPEC® components are designed, specified, or manufactured by Edmund Optics. Learn More

    1310nm Laser Line Coated Plano-Convex (PCX) Lenses

    ×
