Laser Mechanics

Need Help?
Looking for
Custom Optics?

Beam Steering Assemblies Beam Steering Assemblies
  • Ready to Use Beam Steering Assembly
  • High Resolution 100 TPI Kinematic Mounts
  • Available with 20mm Post for Higher Stability
Cage OBIS™ Combining Kit New
×
Cage OBIS™ Combining Kit
  • Used to Combine Two OBIS™ Lasers
  • Easy to Align
  • Intuitive Design
  • Optics and Lasers Sold Separately
Dual Axis Galvanometer Scanning System New
×
Dual Axis Galvanometer Scanning System
  • Dual Axis Scan Range of ±20°
  • 7mm Mirrors with Protected Silver Coating
  • Driven by Intuitive ScanMaster Designer Software
Single Axis Galvanometer Optical Scanners New
×
Single Axis Galvanometer Optical Scanners
  • ±10° of Optical Scanning
  • Designed for Stable Positioning at Fast Scan Speeds
  • Compact Form Factor for Space Sensitive Applications
Acktar Blackened Laser Beam Traps and Blocks New
×
Acktar Blackened Laser Beam Traps and Blocks
  • Coated for High Absorbance of Laser Light
  • Tubular Beam Trap or Thin, Flat Beam Block Designs
  • M6 Tapped Hole for Easy Post Mounting
Optotune Beam Steering Mirrors New
×
Optotune Beam Steering Mirrors
  • ±50° of Optical Scanning
  • Protected Gold or Silver Coated Mirror Options
  • Compact 45mm Diameter Housing Footprint
  • Control via USB, SPI, or Analog Input
Coherent® OBIS™ Heat Sink
TECHSPEC® components are designed, specified, or manufactured by Edmund Optics. Learn More
Coherent® OBIS™ Heat Sink
  • Designed for Coherent® OBIS™ Lasers
  • C-Mount and Cage System Compatible
  • 10 Heat Sink Fins
Dual Axis Galvanometer Optical Scanners Dual Axis Galvanometer Optical Scanners
  • Advanced Optical Position Detector Design
  • Moving Magnet Actuator Technology
  • Compact Size for Easy Integration
High Power Beam Dumps High Power Beam Dumps
  • 50W Max Input Power
  • Available in Metric and Imperial
Laser Diode Mounts Laser Diode Mounts
  • Compatible with a Variety of Laser Diode Modules
  • Multiple Mount Configurations
  • Compatible Diameters from 9.5-16mm
Metric Beam Dump Metric Beam Dump
  • Absorbs Unwanted or Unused Laser Beams
  • 10mm Entrance Aperture
  • Posts and Post Holders Required for Mounting
Metric Spatial Filters Metric Spatial Filters
  • X-Y Micrometer Translation
  • Gimbal Tilt Control for Fiber Alignment
  • Z-Axis Translation for Objective Mount
Mounting Accessories and Power Supplies for Lasers Mounting Accessories and Power Supplies for Lasers
  • Common Power Supplies and Mounts for Lasers and Laser Diodes
  • Ideal for Blue and Violet Laser Diode Modules
  • Various Sizes and Materials Available
Optical Chopper Optical Chopper
  • Includes Five Interchangeable Chopping Discs
  • Frequencies Ranging from 5Hz to 20 kHz
  • Miniature and Standard models available
Spatial Filter Movement Spatial Filter Movement
  • X-Y Adjustable
  • Pre-Mounted on a Gimbal Tilt-Table
  • Open-Style Design

View all Resources Related to Laser Mechanics
