New Optics

• Excellent Mid-Wave IR (MWIR) (4 - 5µm) Transmission
• Available in 5, 10, 12.5, and 25mm Diameters
• Commonly Used in White Light Generation

• Ultra-Thin ≤0.55mm Substrates for OEM Integration
• Options For 600-1100nm and 700-1550nm
• Wide Acceptance Angle Tolerance of ±10°

Low Cost Alternative to Silicon, ZnSe, and Germanium Lenses

Suitable for Applications in the 1650 – 2500nm Wavelength Range

Various Coating Options: Uncoated, MgF₂, VIS 0°, VIS-NIR, NIR I, NIR II, VIS-EXT, and YAG-BBAR

• Corning 7979 IR Grade Fused Silica Substrates
• Broad Transmission Range from 200 – 3500nm
• λ/10 Transmitted Wavefront Distortion
• Excellent Thermal Stability

• High Reflectivity at 1030nm and High Transmission at 940nm
• Low Group Delay Dispersion (GDD) <±100fs²
• Dichroic Mirror Ideal for Ytterbium (Yb) Lasers

• Designed for Filter Threadless Imaging Lenses
• Available in UV, VIS, NIR, and SWIR Wavelengths
• ≥80% Transmission

• Ultra-Thin 0.1mm Thickness Substrates
• Enhanced Aluminum Coated for High Reflectivity in the Visible Spectrum
• Ideal for Weight and Space Sensitive Applications

• Simultaneously Collimate Light from Laser Diode Fast and Slow Axes
• Circularize Elliptical Output from Common Blue Laser Diodes
• Ideal for Light Collimation of Single Emitters in the Blue Spectrum

• Transmissive Adaptive Optics for Wavefront Correction
• Visible AR Coating for >97% Transmission
• Ideal for Aberration Correction in Microscopy Applications

• High Efficiency, Angle Bending, Batwing, and Elliptical Configurations Available
• Transmission Efficiency >88%
• Low-Cost, High-Performance Diffusers

• OD ≥8 Blocking and >95% Minimum Peak Transmission in the Passband
• Designed for Common qPCR Fluorophores
• Excitation Filters and Emission Filters Available

• Narrow 10nm Bandwidth
• Lightweight, Flexible, and Ultra-Thin 400µm Thickness
• Scratch Insensitive and Durable Design

• High Quality Fused Silica Substrate
• <10Å Surface Roughness for Low Scatter
• 90° Offset Angle for Easy Integration

• UV, Visible, and NIR Anti-Reflection Coated Versions Available
• λ/10 Transmitted Wavefront Distortion
• Circular and Square Sizes from 2mm to 150mm
• 1λ or λ/4 UV Fused Silica Windows Also Available

• Available Uncoated or BBAR Coated for UV, Visible, and NIR
• Ideal for Imaging Applications
• Circular and Rectangular Sizes from 5 to 200mm
• 1λ or λ/10 UV Fused Silica Windows Also Available

• Enhanced Reflectivity and LIDT over Metallic Coatings
• Average Reflectivity >99% Over Broad UV, Visible, and NIR Wavelengths
• Designed for all Polarization States from 0 – 45° AOI

• Features Extreme Surface Hardness Chemical Resistance
• Transmits Wavelengths Ranging From UV to Mid-Infrared
• Thinner and Stronger than Standard Glass Windows
• Anti-Reflection Coating Options Covering 350 - 5000nm Available

• Ideal for Gas Analysis
• Center Wavelengths of 2.7-12.4μm
• Single Substrate Interference Filter

• Excellent Transmission in the UV
• Hexagonal Aperture Maximizes Throughput
• Perfect for Non-Uniform Light Sources
• Additional Light Pipe Homogenizing Rods Available

• Low Dispersion
• Available Uncoated or AR Coated
• Ideal for Thermal Imaging, FLIR, and Medical Systems

• Splits Input Image Into Two Paths Separated by 180°
• Variety of Sizes and Broadband Coatings Available
• Additional Right Angle Prism Options Available

• Circular and Rectangular Sizes from 2mm to 200mm
• 8 Broadband Anti-Reflection Coating Options Available
• World's Largest Selection of Standard N-BK7 Windows
• Also Available with Ultra-Thin N-BK7 Windows

• Precision ZERODUR® Substrates
• λ/10 Flatness
• Low Coefficient of Thermal Expansion

• Precision Fused Silica Substrate
• Variety of Sizes and Coating Options Available
• Low Coefficient of Thermal Expansion

• Ultra-Thin 0.20mm Thickness
• UV Fused Silica Substrates
• Extremely Lightweight

• Consistent Transmission from 350 – 1100nm
• Optical Densities from 0.1 to 3.0 Available
• Combine Filters for Custom Optical Densities

• AR Coated to Provide <0.5% Reflectance per Surface for 350 - 700nm
• Designed for 0° Angle of Incidence
• Negative Focal Lengths for Beam Expansion or Light Projection Applications
• Additional AR Coating Options Available: Uncoated, MgF₂, VIS 0°, VIS-NIR, YAG-BBAR, NIR I, and NIR II

• Splits Input Image into Two Paths Separated by 180°
• >99% Average Reflectivity Over 400 – 750nm
• Additional Right Angle Prism and 90° Specialty Mirror Options Available

• BBAR Coatings from the UV to the NIR
• Ideal for Low Power Laser Sources
• Sizes Ranging from 5 – 25mm

• <0.25% Reflection at 785nm
• 5 - 50mm Diameters Available
• 10 - 250mm EFL Designs Available
• 405nm, 532nm, 1064nm, and 1550nm V-Coated Options Offered

• Ultra-thin 300µm Construction
• OD ≥4.0 Blocking and >85% Average Transmission
• Lightweight and Scratch Insensitive

• Ultra-thin 300µm Construction
• OD ≥4.0 Blocking and >85% Average Transmission
• Lightweight and Scratch Insensitive

• HDAR Coating Achieves Severe Abrasion Requirements of MIL-C-675C
• Low Reflectivity Across the VIS-NIR
• Ideal for Use in Harsh Environments
• Uncoated Fused Silica Windows Also Available

• Durable Sapphire Substrates Ideal For Material Processing and Advanced Manufacturing
• Designed and Coated at 1064nm
• Diffraction Limited Performance at 1064nm

• Enhanced Reflectivity and LDT over Metallic Coatings
• Average Reflectivity >99% from 400 – 750nm
• Designed for all Polarization States at 0 – 45° AOI
• λ/10 Versions Available

• High Performance Phase Modulation up to 1MHz
• >98% Transmission from UV to NIR Spectra
• >10 J/cm² Damage Threshold
• Ideal for Q-switching, Pulse Picking, and Laser Power Control
