Products / Optics / Optical Mirrors / Specialty Mirrors

Specialty Mirrors

Need Help?
Looking for
Custom Optics?

CONTACT AN EXPERT


CHAT   EMAIL

Category
    Diameter (mm)
    to
    Coating
    Coating Type
    Dimensions (mm)
    Substrate
    Surface Flatness
    Wavelength Range (nm)
    Cailabs Canunda Reflective Axicons New
    ×
    Cailabs Canunda Reflective Axicons
    • High-Power Bessel Beam Generation via Reflective Design
    • Eliminates Chromatic Dispersion for Ultrafast Laser Applications
    • Multiple Axicon Angles and Coating Options Available
    • Includes Manufacturer's Certificate of Specification Conformity
    Optotune Beam Steering Mirrors New
    ×
    Optotune Beam Steering Mirrors
    • ±50° of Optical Scanning
    • Protected Gold or Silver Coated Mirror Options
    • Compact 45mm Diameter Housing Footprint
    • Control via USB, SPI, or Analog Input
    Cold Mirrors Cold Mirrors
    • 0° and 45° Angle of Incidence Options Available
    • Reflects 90% of Visible Light
    • Transmits 80% of the NIR and IR
    Hot Mirrors Hot Mirrors
    • Ideal for Reducing Heat
    • Reflects 90% of the NIR and IR
    • Transmits 80% of Visible Light
    Knife-Edge Pickoff Mirrors
    TECHSPEC® components are designed, specified, or manufactured by Edmund Optics. Learn More
    Knife-Edge Pickoff Mirrors
    • Designed to Separate Two Beams Propagating Closely Next to Each Other
    • 45° Bevel
    • Coating Aperture Up to the Knife-Edge
    • Enhanced Aluminum, Protected Gold and Protected Silver Coating Options
    Extended Hot Mirrors Extended Hot Mirrors
    • Improved NIR Reflectance Over Standard Hot Mirrors
    • Operating Temperatures up to 230°C
    • Neutral Color for 5500K or 3200K Sources to ±250K
    High Performance Hot Mirrors
    TECHSPEC® components are designed, specified, or manufactured by Edmund Optics. Learn More
    High Performance Hot Mirrors
    • >90% Transmission from 400 - 690nm
    • >95% Reflection from 710 - 1150nm
    • Ideal for Minimizing Heat Build-Up
    UV Hot Mirrors UV Hot Mirrors
    • Transmits 80% of UV and Visible Light
    • Reflects 70% of IR Light
    • Contact Us for Custom Sizes
    High Performance Cold Mirrors
    TECHSPEC® components are designed, specified, or manufactured by Edmund Optics. Learn More
    High Performance Cold Mirrors
    • >95% Reflection from 400 - 690nm
    • >90% Transmission from 700 - 1150nm
    • Optimized for 0° or 45° Angle of Incidence
    Convex Mirrors
    TECHSPEC® components are designed, specified, or manufactured by Edmund Optics. Learn More
    Convex Mirrors
    • Precision Polished Surface
    • λ/2 Surface Accuracy
    • Variety of Coating Options Offered
    Convex Spherical Mirrors Convex Spherical Mirrors
    • Variety of Diameters and Focal Lengths Available
    • Enhanced Aluminum and Protected Gold Coatings
    • Ideal for Imaging Systems
    45° Rod Mirrors
    TECHSPEC® components are designed, specified, or manufactured by Edmund Optics. Learn More
    45° Rod Mirrors
    • Coated and Uncoated Versions Available
    • Use Coated Versions to Reflect Light at 90°
    • Use Uncoated Versions to Bend Image Paths
    Cone Mirrors
    TECHSPEC® components are designed, specified, or manufactured by Edmund Optics. Learn More
    Cone Mirrors
    • Ideal for 360° Applications
    • ±6 Arcmin Apex Angle Tolerance
    • Protected Aluminum Coating
    90° Specialty Mirrors
    TECHSPEC® components are designed, specified, or manufactured by Edmund Optics. Learn More
    90° Specialty Mirrors
    • Splits Input Image Into Two Paths Separated by 180°
    • Variety of Sizes and Broadband Coatings Available
    • Additional Right Angle Prism Options Available

    View all Resources Related to Specialty Mirrors

    Specialty Mirrors are a unique subject of Optical Mirrors that are designed to offer a solution to many of the problems faced when using traditional Optical Mirrors, such as space limitations or wavefront manipulation. Edmund Optics offers a range of Specialty Mirrors to be used in a variety of applications or industries, such as illumination, imaging, or microscopy. Edmund Optics’ Specialty Mirrors include deformable mirrors, rod or cone mirrors, right angle prism mirrors, or convex spherical mirrors.

    Deformable Mirrors, which modify their surface profile to best reflect incoming light, are used for wavefront manipulation or system enhancement applications. Deformable mirrors are ideal for life science instrumentation, Optical Coherence Tomography (OCT), or OEM integration. Cone mirrors are used for 360° illumination. Rod mirrors or right angle prism mirrors are ideal for redirecting laser light at 90°. Convex spherical mirrors, which produce virtual upright images, are used to increase an imaging system’s field of view.
