    Right Angle Prisms

    Right Angle Prisms are typically used to bend image paths or for redirecting light at 90°. Right Angle Prisms are Prisms designed with a 90° angle. Right Angle Prisms produce inverted or reverted left handed images, depending on the orientation of the prism. Using two Right Angle Prisms together is ideal for image or beam displacement applications. These prisms are also known as image reflection or reflecting prisms.

    Edmund Optics offers a wide range of Right Angle Prisms in a variety of sizes, substrates, or reflection or anti-reflection coating options. Aluminum reflection coatings are available for the Prism’s hypotenuse to increase reflectivity. Anti-reflection coatings, including UV-VIS, MgF2, VIS 0°, VIS-NIR, or NIR I, are available for the Prism’s faces to decrease reflectivity in the Ultraviolet (UV), Visible, or Infrared (IR). Laser line anti-reflection coatings are also available for popular laser wavelengths. Substrate options include N-BK7, UV Fused Silica, N-SF11, Calcium Fluoride (CaF2), Germanium (Ge), or Zinc Selenide (ZnSe).

    New
    ×

    Nd:YAG Laser Line λ/20 UV Fused Silica Right Angle Prisms
    • λ/20 Surface Flatness
    • <0.25% Reflection for Nd:YAG Applications
    • 5 - 25mm Sizes Available
    New
    ×

    λ/20 UV Fused Silica Right Angle Prisms
    • λ/20 Surface Flatness
    • UV Fused Silica Substrate
    • Laser Optic Quality

    High Tolerance UV Fused Silica Right Angle Prisms
    • Ray Deviation of 90°
    • Left Handed Image
    • ±40 Arcseconds Angle Tolerance
    • Additional Right Angle Prism Options Available

    UV Fused Silica Right Angle Prisms
    • Ideal for Broadband Applications
    • Available with Aluminized and AR Coated Faces
    • Sizes Ranging from 5 - 50mm
    • Additional Right Angle Prism Options Available

    N-BK7 High Tolerance Right Angle Prisms
    • Ray Deviation of 90°
    • Left Handed Image
    • Low Arcsecond Angle Tolerance
    • Additional Right Angle Prism Options Available

    N-BK7 Right Angle Prisms
    • Ray Deviation of 90°
    • Left Handed Image
    • Available with Aluminized and AR Coated Faces
    • Additional Right Angle Prism Options Available

    Right Angle Mirrors
    • Reflects Light at 90°
    • Ideal for System Alignment
    • Enhanced Aluminum, Protected Gold, and Protected Silver Coatings

    Broadband Dielectric Coated Right Angle Mirrors

    BBAR Coated Hypotenuse Right Angle Prisms
    • Single Axis Retroreflector
    • Right-Handed Image
    • VIS and NIR Options Available

    Broadband Anti-Reflection (BBAR) Coated Right Angle Prisms
    • Ideal for Low Power Laser Sources
    • Multiple BBAR Coatings Available
    • Ray Deviation of 90°

    High Power Laser Line Right Angle Prisms
    • 355nm, 532nm and 1064nm Options Available
    • High Damage Threshold
    • Ray Deviation of 90°
    • Additional Right Angle Prisms Available

    Infrared (IR) Right Angle Prisms
    • CaF2, Ge, and ZnSe Substrates
    • Ray Deviation of 90°
    • Ideal for Use with Collimated Sources
    • Additional Infrared Optics Available

    Laser Line Right Angle Prisms
    • <0.25% Reflection at Design Wavelength
    • Coatings Available for HeNe, YAG, and Diode Sources
    • Ray Deviation of 90°
    • Additional Right Angle Prisms Available

    N-SF11 Right Angle Prisms
    • Ray Deviation of 90°
    • Left Handed Image
    • High Refractive Index Material
    • Additional Right Angle Prism Options Available

    ×
