All Products / Optics / Polarization Optics / Linear Polarizers / Absorptive (Dichroic) Polarizers / Polymer Film Polarizers
Family ID The Family ID is used to identify product family presentations and can be used to quickly access presentations utilizing the search. #3435
TECHSPEC® components are designed, specified, or manufactured by Edmund Optics. Learn More
Top Seller

High Contrast Linear Polarizing Film (XP42)

×
  • High Transmission of Unpolarized Light from 400 – 700nm
  • Excellent Extinction Ratio of 9000:1
  • Available in Custom Sizes
  • High-Temperature Options Also Available
Didn't find your exact size? Get an immediate quote for your specified size here.

Ideal for a range of imaging applications, TECHSPEC® High Contrast Linear Polarizing Film (XP42) features an excellent extinction ratio and high transmission from 400 – 700nm. This polarizing film is offered in multiple thicknesses; thicker polarizing film has increased rigidity. Available in sheets, TECHSPEC® High Contrast Linear Polarizing Film (XP42) can be cut to fit any application need.

Note: Polarizer Film with adhesive available.

Immediate Custom Quotes Available

If you have a need for any round, square, or rectangular size of a TECHSPEC High Contrast Linear Polarizing Film (XP42) in dimensions between 3mm and 600mm, please visit our Polarizing Film Tool.  We’ll provide an immediate quote, and can deliver the part to your requested size in approximately 3 weeks.  A full list of standard manufacturing tolerances and restrictions are listed.  For fully customized polymer polarizers to your requirements, visit our Customized Polymer Polarizers Capabilities page.
