Name: 3" Dia, 30" FL Protected Gold, Spherical Mirror
Brand: TECHSPEC
SKU: 32-834
Price: €311,00

3" Dia, 30" FL Protected Gold, Spherical Mirror

BOROFLOAT^®

Focal Length Tolerance (%):

±2

Surface Quality:

60-40

Surface Accuracy:

λ/4

Diameter (inches):

3.0

Diameter (mm):

76.20 +1.0/-0

Diameter Tolerance (inches):

+0.04/-0

Effective Focal Length EFL (inches):

30.00

Effective Focal Length EFL (mm):

762.00

Radius of Curvature (mm):

1524.00

Aperture (f/#):

f/10

Coating:

Protected Gold (700-10000nm)

Coating Specification:

R_avg >96% @ 700 - 2000nm
R_avg >96% @ 2000 - 10,000nm

Coating Type:

Metal

Back Surface:

Ground

Edge Thickness ET (inches):

0.50

Edge Thickness ET (mm):

12.70

Edge Thickness Tolerance (%):

+0.0/-15

Type:

Spherical Mirror

Typical Energy Density Limit:

0.8 J/cm² @ 1064nm, 10ns

Wavelength Range (nm):

700 - 10000

0.8 J/cm² @ 1064nm, 10ns

Regulatory Compliance

RoHS 2015:

Compliant

Reach 224:

Compliant

Certificate of Conformance:

View

Product Family Description

Ideal for Multispectral Focusing Applications
Variety of Coating Options Offered
Multiple Sizes Available
λ/8 Precision Spherical Mirrors Also Available

TECHSPEC® λ/4 Precision Spherical Mirrors are designed for research and technical OEM applications in the UV, VIS, or IR ranges. Each size is available uncoated or with one of our various reflective mirror coatings.
