Name: 51 x 76mm, 75R/25T, Plate Beamsplitter
SKU: 31-432
Price: €79,00

51 x 76mm, 75R/25T, Plate Beamsplitter

Stock #31-432

- +

€79,00

Qty 1-9
€79,00

Qty 10+
€59,00

Volume Pricing
Request Quote

+ Add to Saved List

Compare

Get Product Downloads

Coating Specification:

Surface 1: Dielectric, ±5% R/T @ 550nm
Surface 2: Uncoated

Construction:

Plate

Dimensional Tolerance (mm):

±0.38

Dimensions (mm):

51.0 x 76.0

Edges:

Cut

Reflection/Transmission Ratio (R/T):

75/25

Float Glass

Surface Flatness (P-V):

4 - 6λ

Surface Quality:

80-50

Thickness (mm):

3.00

Type:

Standard Beamsplitter

Wavelength Range (nm):

400 - 700

Regulatory Compliance

RoHS 2015:

Compliant

Certificate of Conformance:

View

Reach 233:

Compliant

Product Family Description

Low Cost Design
Multiple Sizes Available
Many Beamsplitting Ratios Available

Our Plate Beamsplitters are available in a variety of configurations to meet a variety of application needs. Many are available with an anti-reflection (AR) coated second surface to enhance each beamsplitter’s overall efficiency and to prevent unwanted ghost reflections. For custom sizes or alternate reflection/transmission ratios, please contact our
Sales Department.
