60 SCHOTT Optical Filter Glass Types in Stock
Online Tool for Quick Quotes of Custom Filter Glass Here
No Minimum Order Quantity for Both Standard and Custom Dimensions
Build-to-Print Manufacturing and Full-Custom Design
Rapid Turnaround for Prototypes
ITOS, the German manufacturing site of Edmund Optics®, offers optical filter glass in customized shapes, sizes from 4-160mm, and at various thicknesses. Utilizing state-of-the-art production equipment and an extensive inventory of the entire range of SCHOTT Optical Filter Glass, including a large selection of raw glass plates, allow for rapid delivery of small quantities of customized filters. This DIN ISO 9001:2015 certified manufacturing facility guarantees reliability and quality in volume production. ITOS also supports analysing your filter and providing you the required properties.
Contact us today to speak with an expert or to request a quotation.
Choose from 59 different types of filter glasses to match the spectral requirements of your application. Whether you require small quantities for prototyping or build-to-print manufacturing for OEM systems, or simply need to define the filter specifications, we have the capabilities to cut and polish optical filter glass to ensure the success of your project.
| Optical Filter Glass Capabilities | ||
|---|---|---|
| Dimensions | Ø 3 to 160mm or 2 x 2mm to 160 x 160mm | |
| Dimensional Tolerances | For ≥ 2 – 49mm: ±0.2mm, for ≥ 50 – 99mm: ±0.3mm, for ≥ 100 – 160mm: ±0.4mm | |
| Thickness | 0.5 – 4.0mm | |
| Thickness Tolerances | For ≤ 1mm: ± 0.1mm, for > 1 – 4mm: ± 0.2mm | |
| Surface Finish* | P2 | |
| Form Errors, Planarity* | 3/10-15 for diameters up to 50mm | |
| Surface Defects* | For ≥ 2 – 49mm: 5/3 x 0.63mm, for ≥ 50 – 160mm: 5/4 x 0.63mm | |
| Parallelism* | 3 arcmin | |
| Edges & Bevels | Round parts ≥ Ø5mm: polished edges & protective bevel Square & rectangular parts < 50 x 50mm: polished edges, no bevel |
|
| Edge Chips | For ≤ Ø80mm: < 0.3mm (5/E0.3), for ≥ Ø81mm < 0.6mm (5/E0.6) | |
Color glass optical filters operate through absorption rather than the application of coatings. Many types of color glass filters are available including bandpass, shortpass, longpass, neutral density, heat absorbing, and multiband filters. Click below to learn more about different types of optical filters:
Start Now| SCHOTT Optical Filter Glass Types Available for Customization | |||||
|---|---|---|---|---|---|
| BG3 | BG60 | VG9 | GG395 | GG495 | RG695 |
| BG7 | BG61 | VG20 | GG400 | OG515 | RG715 |
| BG18 | BG62 | UG1 | GG420 | OG530 | RG9 |
| BG25 | BG63 | UG5 | GG435 | OG550 | RG780 |
| BG38 | BG64 | UG11 | GG455 | OG570 | RG830 |
| BG39 | BG67 | BG36 | GG475 | OG590 | RG850 |
| BG40 | RG1000 | N-WG280 | KG5 | RG610 | NG5 |
| BG42 | KG1 | N-WG295 | NG1 | RG630 | NG9 |
| BG50 | KG2 | N-WG305 | NG3 | RG645 | NG11 |
| BG55 | KG3 | N-WG320 | NG4 | RG665 | |
| General Information SCHOTT Optical Filter Glass | |||||
| UG | Black and blue glasses, UV transmitting | ||||
| BG | Blue, blue-green, and multiband glasses | ||||
| VG | Green glasses | ||||
| GG | Nearly colorless to yellow glasses, IR transmitting | ||||
| OG | Orange glasses, IR transmitting | ||||
| RG | Red and black glasses, blocking visible, IR transmitting | ||||
| NG | Neutral density glasses with uniform attenuation in the visible range | ||||
| WG | Colorless glasses with different cut-offs in the UV, transmitting in the visible and IR ranges | ||||
| KG | Virtually colorless glasses with high transmission in the visible and absorption in the IR | ||||
How do I find the correct SCHOTT colored glass filter for my application?
1.) Select the desired spectral characteristics for your filter. Edmund Optics offers SCHOTT longpass, shortpass (heat absorbing), bandpass, and neutral density filters.
2.) Define the required wavelengths for the application. Specifically, determine which wavelengths should be blocked (absorbed) and which wavelengths should be transmitted through the filter.
3.) Choose the required dimensions (including thickness and tolerances) and the mechanical specifications (unpolished, polished, or hardened).
4.) Edmund Optics offers a wide variety of standard SCHOTT colored glass filters, in stock and available for immediate delivery. If your application requires a simple modification to a filter’s size, our Colored Filter Glass Pricing Tool is available for rapid customization. We also offer full customization services for all SCHOTT colored glass filter types.
Are SCHOTT NG Gray Glass Neutral Density (ND) Filters suitable for absorbing visible light in defined steps?
Edmund Optics offers SCHOTT NG Filter glass types in two distinct families. The SCHOTT NG Gray Glass Neutral Density Filters are designed for applications where the thickness of the filter is critical. While these filters will provide consistent transmission values from 400 - 700nm, variations in filter lot manufacturing may lead to variations in transmission from filter to filter.
If your application requires a specific transmission (optical density), Edmund Optics also offers SCHOTT NG Absorptive Neutral Density Filters. Each lot of these filters is measured and the thickness is adjusted to meet the specified transmission value at 546nm. Each filter is then polished to a ±0.05mm thickness tolerance to guarantee consistent performance. Variations in filter lot performance can result in variations in nominal thickness; however, the transmission variations between lots will be minimal. All SCHOTT NG filter types can be customized for your specific requirements.
Do all SCHOTT Colored Glass Filters have a chamfer?
Dimensions >50mm are delivered with a protective chamfer. Dimensions ≤50mm (round or square) are supplied without a chamfer but a chamfer can be applied upon request.
Does Edmund Optics supply colored glass filters from other manufacturers?
Edmund Optics works with a variety of glass manufacturers worldwide and is able to support a wide range of colored glass materials. What’s more, our ITOS Manufacturing facility in Mainz, Germany has an extensive selection of SCHOTT material in stock and available for rapid customization and delivery. There may be substantial lead times for any colored glass materials from manufacturers other than SCHOTT.
Is KG range glass (i.e. KG1, KG2, KG3, KG5) suitable for use as laser protection? Am I able build my own laser safety eyewear using these filters?
Edmund Optics does not recommend that anyone build their own laser safety eyewear from the filters we offer. There are a number of global standards, including ANSI Z136, and EN 207/EN 208/60825 that should be strictly adhered to when manufacturing laser safety equipment. However, Edmund Optics does offer a wide range of Laser Safety Eyewear available for purchase. Always work with your organization’s laser safety officer to determine the required level of eye protection.
